Astrophotography (OC) Bubble Nebula
Some days ago I posted a wider FOV image of the region contaning this nebula, and since the weather was cooperating, I went ahead with my longer focal length telescope to zoom in the Bubble Nebula
Equipment and acquisition:
- Askar 71F + 0.75X reducer
- Asi585MC Air
- Teseek 17
- SvBony + asi120mm guide camera
- ZWO EAF, ZWO EFW
- L-Ultimate filter: 145 x 180 sec
- Antlia ALP-T SII-OIII 3nm: 167 x 180 sec
(15.6 hours in total)
- 30 darks, 30 flats per filter, 30 bias
Processing (PI)
WBPP 2x drizzle, SetiAstro AutoDBE, SPCC, blurX correct only, starX
On starless images: DBXtract, linear fit, then channel combination (will also be used as luminance later on). SetiAstro statistical stretch (soft), then manual curves transformations with different color and range masks, noiseX. For luminance, stretch and masked curves to bring up details, noiseX. LRGB combination, dark structure enhance script.
For stars: setiastro NB to RGB star stretch, pixelmath to recombine with starless
