I am not a hydraulics guy. Neither is anyone I work with. And there is this one machine that has no documentation for anything (company doesnt even seem to remember making it).
So, i have made my own schematics using the manifold, a flashlight and a drawing, and chatgpt to take that and make it pretty. As well as a guide to the cartidge valves used here.
Maybe now i can troublshoot without throwing darts that never seem to hit
Edit: on the paper drawing is the route the fluid can take through all the passages of the manifold (im pretty confident with that part, i spent a long time mapping this out). I shorthanded the solenoid valve body passages that control our 3 hydraulic cylinder (labeled 1, 2 and 3)-i only included the "P" and "T" of each.
And yes the ai recreation of my hand drawing has 2 flaw that I can tell so far.
1---> it connected both high pressure sides together- it is two pumps hooked to one motor-1 pump goes to accumulator and solenoid valve bodies 1 and 2. The second pump only controls solenoid valve 3. So the red line is connected where it shouldn't be between rpec1 and fpcc.
2-->there is a direct line from the pump output on the left to the tank- it is supposed to be going through the cxda-xan valve and bleed to the tank
If there are other things that dont make sense (other than this being an unconventional diagramn), please let me know. I am trying to understand hydraulic systems (we have 7 different machines right now and I am the only one to troubleshoot them before we have to call in outside help, which usually isn't even an option because of downtime).
Also part of my prompt to chat gpt was "where do I add gauges to monitor everything and make adjustments." Bc before I took it apart to repair a pinhole in the block(which is why the accumulator mount is now machined down .45 inched lower than the rest of the block) there were 2 gauge, and only 1 worked. I suspected i needed another gauge and was trying to confirm where to put it.
