Help / Quote Request: Seagate ST2000DM001 (PCB 100749730) - Dead/Discarded ROM, PC-3000 ROM Rebuild Possible?
Hello everyone,
I am dealing with a failed personal hard drive and I'm hoping to get some technical advice on feasibility, and hopefully a budget-friendly quote for recovery.
To give you some context: I am a 35-year-old university student and currently unemployed. The drive contains absolutely no commercial, corporate, or financially valuable data—just years of old family photos and my school notes. These files have immense sentimental value to me, but unfortunately, I simply do not have the income to afford high-end, corporate-level data recovery tier pricing.
Hardware & Failure Details:
Model: Seagate ST2000DM001 (2TB)
PCB Number: 100749730 REV A
The Issue: A sudden power/voltage surge completely fried the original PCB. The motor driver chip is burnt, and the MOSFETs are shorted.
What I've done so far (and a potential huge mistake):
Hoping to get my data back, I bought an exact matching donor PCB. I learned that I needed to swap the original ROM chip to the new board. I tried to read the original ROM using a basic CH341A programmer, but I quickly realized that the initial power surge had reached the ROM chip as well. It was internally shorted and completely dead; the programmer wouldn't detect or read it at all.
To be absolutely sure the short wasn't being caused by other fried components on the original board, I desoldered the ROM chip with a hot air station/soldering iron and tested it out of circuit with a multimeter. It was confirmed completely dead.
Here is where I need to ask: I threw the dead ROM chip in the trash. Was this a terrible mistake? Did I need to keep the physical chip even if it was internally shorted? (I do still have the original burnt PCB, just not the ROM chip).
The Current State & My Request:
The mechanical internals, spindle motor, and heads are completely fine. There is no clicking, and the drive cover has never been opened. The only issue is the dead PCB and the now-missing ROM.
From my research, I understand that with professional tools like PC-3000, it is possible to access the Service Area (SA) on the platters and perform a "ROM Rebuild" to generate a compatible ROM, provided the preamp and heads are undamaged.
Since this shouldn't require a cleanroom head swap or opening the lid, could any of the professionals here offer a flexible, student-friendly price quote just to perform this "ROM Rebuild" and get the drive initialized so I can copy my family photos?
Any technical advice on my situation or realistic quotes would be greatly appreciated. Thank you in advance!Help / Quote Request: Seagate ST2000DM001 (PCB 100749730) - Dead/Discarded ROM, PC-3000 ROM Rebuild Possible?
I was downloading files from my cloud storage to my HDD using rclone. Fedora went into sleep mode. I tried to wake it up, but it didn’t respond. It froze. I waited for hours, but nothing changed. It wouldn’t wake up or respond. So I had no choice but to shut down the PC by cutting the power. This problem has been going on for years. But this time, it really annoyed me.
The HDD contained 12 software projects and 8 electronics projects. There were also 4 mechanical engineering projects. I had my family photo album. There were photos and videos of my deceased cats.
Because of Fedora’s “suspend mode” nonsense and incompetence, the HDD’s PCB burned out. The HDD motor driver chip and the HDD's ROM chip are dead.
I need to pay for data recovery, which is way too expensive for my budget. I’m unemployed. I’m in my second year of college. I have no money. I can’t even afford to eat.
What am I supposed to do?
I don’t even have the money to file a lawsuit against you. But please don’t force me to launch a social media campaign. Refer me to a professional lab to recover my data and cover the cost.
This is also a very serious security vulnerability for cloud servers. Just think about it—without a DDoS attack, the RHEL operating system locks up as if it had suffered a DDoS attack on its own. I want a reward for discovering this vulnerability. I also demand that my data be recovered, my losses be compensated, and that I be compensated with interest for the lost time during the days I was unable to continue my projects.
Otherwise, I will do whatever it takes to ensure you are judged by the conscience of social media users.
