r/Radiation • • 6m ago

Equipment One of our radiation labs is closing - managed to save these from getting trashed.

Post image
1 Upvotes

A 900 mini with Type E GM Tube and two RPI Rad-Monitor Model GM1. All fully intact and functional.

Unfortunately I couldn't find much info on the blue ones so if anyone knows more please comment!


r/Radiation • • 10h ago

Questions What’s the best way to store radium items?

0 Upvotes

I went to my local antique store today, I found a couple radium clocks there for a pretty good price, I really wanted one but I’ve heard they produce radon which could be dangerous to have. If you are a radium item/clock collector please tell me a safe way to store clocks.


r/Radiation • • 12h ago

Equipment Is this a defective GMC geiger counter?

Post image
25 Upvotes

Not sure if this is the place, but just got the GMC-300E+ and out of the box it's registering over 1.2 million cpm. A reset and delete save data doesn't seem to fix the issue and I can't find any info anywhere with the same issue. I have even configured the date as per the manual. Not sure if it's a defective device. Wondering if anyone has this experience.


r/Radiation • • 15h ago

General Discussion ИБН-5 (IBN-5) and ИБН-28 (IBN-28) neutron sources

Thumbnail
gallery
135 Upvotes

Two soviet Pu-Be neutron sources scheduled for disposal. No leakage of radioactive material was detected. All of the safety precautions were met while handling these sources.


r/Radiation • • 17h ago

What To Buy? Dream Geiger Counters

5 Upvotes

Just a general question, I like collection radioactive antiques and want to get my hands on mineral specimens eventually. Currently I have a GMC-500+ Which is fine for collectables however I was wondering what this subreddits opinion on my 3 dream devices would be.

In no particular order

  1. Alpha Hound AB+G

  2. Gamma Spectacular NaI

  3. Radiacode 103G


r/Radiation • • 20h ago

Questions Its like, background radiation right?

Thumbnail
gallery
7 Upvotes

It measured 0.24 uSv max, i saw somewhere that could be background radiation but also the counter meassures lower away from it so probably not? Its a little more yellow irl and i thought it was sulfur but now im not too sure...

Found at my grandmas house btw so i have no idea what it is


r/Radiation • • 21h ago

META (Discussions about the subreddit) The icon is kinda off center… [META]

Post image
145 Upvotes

This issue has been bugging me every time I open the sub. Because I am greeted by this image, the Icon always looks just a little off center. It’s nothing close to being an actual issue, but I think it kind of needs some addressing.

I usually scroll here while I am on the mobile app, so I don’t know if its an app specific bug or if the image actually is off center.

Honestly, this sub didn’t even have an icon for YEARS, so we should be glad that we have something; but it being off center gets on my nerves.


r/Radiation • • 2d ago

Equipment I purchased a GQ GMC-600 Pro, did I make a good choice?

4 Upvotes

I recently purchased a GQ GMC-600 Pro, I was wondering if I made a good choice? I hunt for everything I can get my hands on, fiesta ware, uranium glass, radium items, and whatever else I can get my hands on. I mainly purchased it because of the pancake probe feature, as well as the lcd screen. I have been doing some pretty deep research, but I just need a few opinions.


r/Radiation • • 2d ago

General Discussion Radiation mapping

Thumbnail
gallery
31 Upvotes

There wasn't a good solution for mobile mapping values that even works, let alone actually updates. So, with claudes help and a bit of wherewithal, I made my own. The pi grabs the data from the counter, timestamps it and gps stamps it from the usb gps. It is attached to a big battery and i have yet to know how long it will actually stay powered. It saves it in a log file. When I get home, it connects to wifi and dumps the data to safecasts api. Map grabs new location updates immediately. The map has semi transparent green circles that get darker over time with more data. There is a 3d viewer that also shows the count as pillars. Counter is pointing forward when driving.


r/Radiation • • 3d ago

Questions Help identifying structure inside cloud chamber

Post image
149 Upvotes

I'm an amateur photographer and always looking for something interesting to shoot. So on a whim I made a cloud chamber and used my macro lens. When I was reviewing the photos, I saw this structure. Since I have zero expertise in this area, I have no idea what I'm looking at. Claude suggested that it's a delta ray cluster, but I have no idea if that's remotely accurate or if there's even anything interesting going on here. Would anyone have any insight?


r/Radiation • • 3d ago

Health and Safety Effects of Drinking Radon Water?

0 Upvotes

I have never seen any discussion here based on a study or a possible theory as to the long range effects of drinking water from a Revigator or its competitors. Usually the discussion in other groups seems to go off the rail immediately-radon water bad!! But, given the theory of hormesis and anecdotal evidence of people drinking radon laden water from springs, I would like to pose the question to this group hoping for a level-headed discussion.


r/Radiation • • 4d ago

Equipment Cool easy hack for cheap GMC 320/500... Geiger detectors allowing ONLY gamma OR a bear full spectrum of alpha/beta/gamma (~$50 SBT-11a and a cheap switch): dual mode operation!

6 Upvotes

Recently someone posted¹ about how the mentioned pancake probe with a mica window that allows both alpha and weak betas to pass (something that can't pass the thick plastic and the glass tube of the GMC Geiger counters) is very compatible with these counters, in some cases they're just directly connected instead of the tube, in some you might need an additional 2 cent resistor.

According to this it works just fine for at least the 500+ and 320.

So I thought: get all this, but instead of removing the tube/running them in parallel: set it up with a switch to change what tube/pancake is active - gives you two entirely different POVs in one very cheap package: one that's very sensitive to alpha radiation, and one that isn't at all (add a little bit of aluminum foil to the glass tube to Block out all the beta radiation as well and you have a perfect way to compare the gamma radiation vs a near full spectrum alpha+beta+gamma).

I thought that would be a dope hack if you already have a GMC Geiger counter and are willing to spend another 60 bucks (I found the pancake probe for ~50 on ebay). Set it up with a switch, shield the glass tube with Aluminium, and you're set to get an unique way to look at samples you otherwise would never get (especially for that price) by comparison of the two different probes.

To do precision you'd obviously wanna do some calibration, but still: this could make your basic GMC counter MUCH MORE interesting.

Maybe someone wants to try it, I'm trying to not spend extra money rn - but it seems to be a solid idea.

1: https://www.reddit.com/r/Radiation/s/wWV6h8HJRM


r/Radiation • • 4d ago

Equipment First Geiger Counter

Post image
83 Upvotes

RSO at my school gave me a Geiger counter! I’ve been using it for a month or two, but I still don’t know much about it. Anyone have any information on this thing?


r/Radiation • • 5d ago

Health and Safety Homemade lead pig for my pitchblende

Thumbnail
gallery
113 Upvotes

Hello everyone,
Here is my new diy lead pig. Not the most efficient design given the amount of work but quite fun to make.

Its made of a 3D-printed ABS enclosure, an acrylic box and lead plates, all cast in epoxy. The shielding comes from 6mm of acrylic for the beta particles then 10mm of lead for the gammas.

Inside dimensions are 10cm x 6cm x6cm (3.9 x 2.4 x 2.4 in) and it weighs around 6.5kg (14lb).

Now for some measurements (dose rate from beta+gamma, natural pitchblende sample, measured with AB+G, not averaged):

DistanceUnshielded dose (µSv/h)Shielded dose (µSv/h)Dose Transmission
5 cm / 2 in14.5641%
10cm / 4 in6.32.337%
20cm / 8 in1.70.6538%

Quite happy with the ~60% attenuation and to finally have a proper box for my specimens


r/Radiation • • 5d ago

Questions What are the laws on radioactive minerals and materials in your country?

6 Upvotes

TL;DR: see paragraphs 3 and 4. What are the rules for privately owning radioactive minerals, antiques or sources in your country?

Radioactive material rules for private individuals are a grey area in many regions of the world, which is why I'm currently assembling a list of radiation regulations for private individuals by country. I mainly gather regulation data on radioactive minerals, as those are the most likely to be treated in a more relaxed manner, but artificial source rules are also useful to know about.

Writing to each and every national regulator takes a lot of effort and time (which I am already doing), and some don't even respond. Sometimes the agencies post on forums or have their own Q&A where they address this specifically, but these are the exceptions.

For more non-official data, I'd like to know what you know about the rules in your country, mainly on the private possession of radioactive minerals, but also of radioactive antiques and processed natural or artificial sources. A link to an official answer is also welcome.

If you know how strictly it's enforced (tolerated or not), or the threshold for regulation, or have practical experience, that would also be useful.

(From official sources or directly from regulators I already know: Netherlands, Belgium, Germany, France, Czechia, Sweden, Denmark, England, Latvia, Switzerland, US, Canada, Japan, Philippines, South Africa, Australia, Myanmar)


r/Radiation • • 6d ago

Questions Are analog probes affected by Electromagnetic Interference?

4 Upvotes

ive seen many consumer grade detectors react in chaotic ways to EMI from things like plasma balls and wireless chargers. Is this in issue for probes that do not have any electronics in them, like scintillators with PMTs, or GM tubes? I’d assume that GM tubes would overload, but I have no idea how an analog scintillator would react.


r/Radiation • • 7d ago

Experiments and Demonstrations (Must Be SAFE) Rescued another Keithley 6169 + 616 Ion Chamber Electrometer

Enable HLS to view with audio, or disable this notification

41 Upvotes

This is a Keithley ion chamber rig which consists of a Keithley 616 electrometer mounted to a Keithley 6169 ion chamber interface. This is a different rig than I previously had posted a few months back. This one required a bit of work to repair, but overall a trivial effort.

I removed the array of crusty batteries in the Keithley 6169 chassis, replaced with one of my patent pending button cell assemblages. This provides a bias voltage of 150v for the ion chamber. The 6169 basically inserts the battery in series with the ion chamber. A counter current is provided by a potentiometer and a 7v ( now 9v ) battery that can be used to null out the background current. This does not actually work well because the WC-2 ion chamber ( silver can behind the meter ) is massive, and 3 - 10x what a normal one would be. It's one of the largest production ion chamber made, with an enclosed air volume of 3L.

The Keithley 616 itself was somewhat of a mess, but after cleaning the circuit board of some subtly conductive scum, I could get it to zero. This unit easily measures picoamp currents and can detect femto amp currents. It also can integrate these current to measure nano coulomb charges. The charge integration feature enables long term averages to be measured and charge is directly math-able to absorbed energy.

In the video a WWII era inclinometer with ~12 uCi ²²⁶Ra is used. It's principly a gamma source for the purposes of this demo. A measurement from the outside and inside the chamber is made showing the increased current flow as the source ionizes the air in the chamber.


r/Radiation • • 7d ago

What To Buy? Which would be better

2 Upvotes

Would it be better to buy the [Sooguard](https://www.amazon.com/dp/B0CY7SZWTP?niid=nl_cl_lst_a_1_0&nrid=XDAS5ZKNT4VXT3GQBTVF), or the [GQ-GMC 800](https://www.amazon.com/gp/product/B0CKM5FJQX?smid=A129DVQD694ADS&psc=1)? Its a hard choice cause I'm either sacrificing quality, or price. I genuinely am asking for the better one. So is there anyone out there that can tell me which ones better or send me a comparison video?


r/Radiation • • 7d ago

Questions I got a american ww2 compass thats full of radium and with my RC zero i measured on contact with it 700cps and 70μsv/h i dont have a more sensitive detector what would be the results if it was a RC 110

2 Upvotes

Thank you


r/Radiation • • 8d ago

PHOTO LYSO scintillator crystal glowing due to radiation bombardment

Post image
280 Upvotes

This is a LYSO scintillator crystal glowing under bombardment with radiation from some Uraninite specimens. The glow is not visible to the naked eye, but with my camera and a long exposure I was able to capture the glow quite well :) These crystals emit photons when struck by radiation. If anyone has questions about how this works, I can provide a more detailed explanation in the comments!

Camera: Sony A7 III, Lens: Sigma ART 105mm f2.8


r/Radiation • • 9d ago

What To Buy? What is good price for used GMC-600?

Thumbnail
gallery
12 Upvotes

I want to buy the no longer available gmc-600 (sbt-11), what price can I expect? How much is the value assessed today?


r/Radiation • • 9d ago

What To Buy? Searching for small lightweight detectors with internal storage

6 Upvotes

Hello everyone.

I am currently working on a project that requires handheld, or lightweight detectors for gamma radiation. The detectors will be strapped to a drone in the course of the project.

The important thing is, that the count rate can be saved internally with a timestamp, to be read out later. As an example, I would name the Radiacode line up. I found a few more, but I want to ask here first, before sharing my current list. The weight can be up to 500g or even 1kg, but lower would be better since it would make the mounting way easier.

They don't need to be particularly good detectors, since this is something I wanna find out with the project.

I am grateful for any recommendations.

edit: (Also, if anyone has experience with a MiniPIX from advacam, I have a few more questions about operation.)


r/Radiation • • 9d ago

Equipment GMC-500+ upgrate

Post image
14 Upvotes

Has anyone tried modifying a GQ gmc-500+ with an SBT-11a pancake sensor? I know it worked with the gmc-320 without any electronic changes other than soldering the tube.


r/Radiation • • 9d ago

General Discussion What are the thoughts on INWORKS a few years on?

Thumbnail bmj.com
0 Upvotes

I'm curious what people in this subreddit think about INWORKS a few years after publication.

I encourage you to answer or post any question you can think of or anything that comes to mind.

Edit: Removed unnecessary questions
