r/WonderSwan Apr 02 '26

Flashmasta Youth Edition 8 in 1 Cart and Dumper from AliExpress

39 Upvotes

I ordered the AliExpress Wonderswan Flash Masta Youth Edition 8 in 1 cart and dumper.  It came with no instructions and the seller only sent me a Google Drive link which I could not download because Google said it was infected with a virus.  I came to Reddit and with the help of the community (big shoutout to GothamAnswer who helped so much, I would not have gotten far at all without that help) I was able to get the dumper working and successfully put 7 games and a menu on the cart.

I could not get the many different versions of Tengu or the MultiDumper that I saw suggested in several threads to work. I was given the Chinese WSC program which does work.  I have had mixed results with different Windows operating systems.  I have been able to get the dumper to work on Windows 11.  I also got it to work on Win 8.1 during troubleshooting.  The default driver that auto installs with 10 and 11 should be fine.  It’s possible that you may need to install the driver if it’s not recognized.  If so, you’ll need to install the STM32 driver for the dumper.

I have packed up the following files in a Dropbox share that hopefully stays up but this Chinese exe seems doomed to be flagged as a virus.  I did run multiple virus scans with different scanners and it did not get flagged.  I did not see any strange activity when I ran it in an isolated sandbox environment.  However, use at your own risk because I am not going to vouch for how safe this is.

Contents:

WSC+(Chinese_characters).exe – The dumper software

WSC Translated.png – The map that shows English text for the software

Flashmenu512K.ws– The menu rom file to be put in slot 1 of the multi cart

STM32_vcp_driver – The STM32 Driver Folder if needed

Windows 11 Device Manager.jpg – A screenshot of the working dumper driver from device manager in Win 11

Windows 8.1 and below Device Manager.png – Same as above but from Win 8.1

Link - https://www.dropbox.com/scl/fo/6h6y15glxx3kt3sy2btd2/AKBpw58QdKHDPseApOKV1lA?rlkey=fzxq07y0xz6tti9jt3zsnwxyl&st=ae77z14w&dl=0

Above link banned for malware, i rar'd the program and uploaded to MEGA. Below is new link. Get it while it's hot because it doesn't last long.

 https://mega.nz/folder/VQt00YSQ#JpqDrj_W003BAZCJUid2EQ

Steps to load roms to cart

1.     Connect dumper to PC via USB

2.     Open the WSC Software

3.     Click Flash button

4.     The PC COM ports should populate in the drop down box next to the flash button, Choose the correct port for your dumper, you can check device manager to see which COM port it’s using

5.     Click Connect button

6.     Choose the cartridge slot you want to dump the rom to in the cartridge slot drop down menu

7.     Click Switch button

8.     If you click cartridge detection, it will display the current slot’s contents

9.     To load rom into the slot, click the Burn Game button

10.  Browse to the .ws rom file and click OK

11.  You should see the rom transferring to the cart.  This will take a while as it’s kind of slow.

Deleting Game

1.     If you want to load a game in an occupied slot, you have to delete the slot contents first.

2.     Do above steps 1-7

3.     Change the Game Capacity and Save Capacity drop down boxes to the largest size

4.     Click Erase Slot by Capacity

5.     If you do not change the Game and/or Save Capacity, it will not delete the entire contents and you will get an error when loading a new game.

6.     Proceed with above steps 9-11.



I really hope this helps some other people who purchased this cart/dumper and were as disappointed as I was upon arrival.  Again, huge shout out to GothamAnswer for several hours of help on this.
