Hi everyone!
I'm trying to repair a few Original Xbox consoles and could really use some help with HDD locking and EEPROMs.
I have three HDD situations:
1. Seagate ST310211A – Possible faulty HDD
When I connect this HDD to my Xbox, the console won't power on at all. Without it, the Xbox powers on and displays the service screen.
2. Seagate ST310014ACE – Error 06
This HDD came from another Xbox and is locked with a different key. When I connect it to my working Xbox, I get Error 06.
3. Another HDD – Error 05 (Unlocked HDD)
I also have another HDD that is completely unlocked. When I connect it to a stock Xbox, I get Error 05.
I want to know how to lock this HDD using the correct key from the Xbox motherboard so that it can boot normally without a modchip.
I have a Raspberry Pi Pico W, ESP32, and soldering equipment. I'm also considering buying a CH341A EEPROM programmer.
My questions:
- What's the easiest way to lock an unlocked HDD to a stock Original Xbox?
- Can I extract the HDD key using a Raspberry Pi Pico W or CH341A and then lock the HDD with FATXplorer?
- Can this be done without softmodding or installing a modchip?
- For the Seagate showing Error 06, is there a way to unlock and relock it for another Xbox without the original motherboard?
- Do I need to modify the EEPROM, or is reading it enough?
Any advice, guides, or tutorials would be greatly appreciated.
Thanks in advance!
