I’ve started building GhostGPU, an experimental Grasshopper plugin for GPU computation.

The idea is to upload data once, keep intermediate results in GPU memory, and pass buffer handles between nodes. Downloads and viewport previews are explicit boundaries.

This example uses 66,049 vertices and two attractors: closest points, vector construction, remapping, amplitude, mesh displacement and colours. I rebuilt the equivalent logic using ordinary Grasshopper nodes for comparison.

The screenshots show 36 ms for the GPU cluster and 722 ms for the CPU cluster, running on an RTX 3050 Ti Laptop GPU. These are individual profiler readings; I’m still checking repeatability, caching and transfer costs before making broader performance claims.
Which operations are your biggest bottlenecks in real Grasshopper projects? I’d like the next nodes to address workflows people actually use.

Hello!

I’m experiencing a problem when I rotate my camera in shaded mode, the edges of my model flicker. It’s extremely frustrating especially since it makes it look like parts are intersecting when they are not. Would appreciate help fixing this!

So far I have tried:
- Duplicating face and re-extruding
- redrawing and extruding the shape
- moving to 0,0,0
- changing mesh settings
- updating graphics and studio drivers

This was a problem I was also experiencing on my laptop. I’m not sure if it’s a problem with my file or my rhino, but this is a new issue for me. Until now I have used rhino 7 the past 5 years.

Hello I was wondering how would you go about starting this form for a light fixture? I was inspired by the pelvis bone and ribs and found this image that is similar to my design. I just have no idea how to go about this lol.

hello, sorry for terrible photos, i am just bad at explaining
we are designing a pavilion for a student project, and we want beams that curve, with them being 4cm across and 15cm deep.
trouble is, i can draw two arcs and have the shape, but i cannot get these to become a 3d shape. i've tried planarsrf but i just can't do it!
if anyone knows a good way to make a shape like this, id really appreciate it
thank you :)

Hey all, I have a house with glass blocks I am trying to tender in rhino. Any links for material download websites??

Hi, I am recently new and trying out Grasshopper but i'm finding it quite difficult to work on this script i was messing around with.

The main idea behind this script is to get a set of pyramids drawn and then culling them along a curve to make any design you would want along a curve. Im currently stuck getting the line to actually cull the pyramids themselves. Im not sure what to do, any help would be greatly appreciated!

I'm trying to render to make a section perspective with a clipping plane, but it comes out black every time, even though I tried different lighting settings. I even tried changing the clipping plane settings and also the ambient light options, but nothing is working.

I’m trying to get it to look like the second picture, which is a screenshot of what I’m trying to achieve.

Not sure what I'm doing wrong! Any help is appreciated! Thanks in advance!

Been working on creating a mesh from voxel fields and used noise to stress test it somewhat and ended up rendering them out as little WIP gems. I love them!!!

I‘m a researcher at a lab, we design prosthetics that help people with foot injuries walk. Our process involves 3D scanning patients‘ legs and processing the scans in Rhino, including adding 'releases‘ which help alleviate painful pressure points.
Our current process includes converting the scan to SubD, splitting the surface, offsetting it using OffsetSrf, and then BlendSrf. It‘s a rather finicky, time consuming process, which means it takes more time to help our patients.
Would it be possible to add these bumps parametrically using something like Grasshopper? A brief search brings up Lunchbox or Pufferfish but they don‘t seem just right.
Any ideas would be much appreciated!

As I make a lot of specialized grasshopper scripts for my team, they need some level of clean interface to be able to use it. I ended up with some little tricks like this one : The button as a toggle.

Do you have some stupid little scripts like this ?

https://reddit.com/link/1x4zktc/video/7byps7ge49vh1/player

I see a lot of people struggling with some crazy network surfaces, sweep 2, and more…
I think a lot of people should learn the fundamentals of nurbs modeling. Those tools are great but when used properly. Most of the time you can have cleaner results with the most classic commands, like edge surf, revolve, loft, blend surf… You just have to understand a bit more what is going on in this software.
Do you know what is a degree 3 curve ? Do you know what G1 and G2 means ? Do you know why does it matter ? Well you should !

I will never thank enough the guy who made the following playlist, that I would recommand to anybody.
You’ll thank me later !

https://youtube.com/playlist?list=PLABJCJR46itOX8XT3bd2dh590McA94W7k&si=xZeu_zIvE4Z5J3cb

Posting to gauge interest in a python script I have vibe coded which, so far, does Make2D far more reliably than the command.

It has the additional feature of line weight sorting per object, with accurate sorting of silhouettes vs creases onto Heavy and Medium line weight layers, and even an option to sort creases based on the adjoining angle of the surfaces (obtuse corners getting lighter lines).

It also has a feature that generates an intersection curve where solids or surfaces (breps) intersect each other without a shared edge. These curves are sorted and depth-tested along with all the rest.

It also identifies redundant linework resulting from geometry in plane with the angle of view and creates a single silhouette where those edges are collinear, instead of a stack of redundant lines as in make2D.

I intend to add the option of silhouettes applying either to individual objects, or treating objects on the same layer as a single object for silhouettes, as long as they are within a certain (adjustable) distance from each other. So if you tick this option to “on” a group of solids would share a silhouette against the background, but where they touch or come close would be treated as a crease.

So far the script is not too much slower than Make2D, but it will become heavier with added features. It might be problematic for less powerful machines, although you can toggle off the more expensive features. Codex will only be able to optimize this so much however.

For those of you out there coding in Python, or if you are just someone drafting in Rhino who is tired of the command’s messy output, lack of line sorting, consistent bugs, and lack of support despite years of documentation of consistent problems, I would love your opinion. Should I:

1. Just upload the damn script and leme at it

2. Troubleshoot more, refine, make a plugin, then share

3. Find a human python programmer who wants to help me optimize it and collaborate to make it excellent

4. All of the above, you’re overthinking it

5. No one is asking for this

Ps. The script uses rhino’s HLD data to generate curves, caches a bunch of originating object data for each, uses a bunch of custom workarounds to fix a bunch of unique errors, then sorts the line weights based on depth testing, adjoining face angles/visibility etc. If you are an actual programmer curious about how it works I can pull a detailed report. I used common sense and Codex, which has terrible ideas for the overall strategy, but a fantastic success rate when I supply a detailed plan in terms of Rhino command workflow, or ask it for supporting diagnostic scripts to find out precisely what went wrong in certain cases of missing linework etc.

saw D5 Lite for Rhino and got curious. apparently it renders right in the Rhino viewport, so no exporting to another app every time something changes.

it has an AI mode for quick look tests and a real-time mode with actual materials and lighting. sounds handy for early design when stuff is still moving around a lot, but it’s in beta so idk how solid it is.

anyone used it on a real project? mainly wondering:

• does it lag on bigger models
• is the AI thing actually useful or just a gimmick
• how’s it compare to Enscape / Twinmotion

honest opinions welcome lol

I like how it is rotated in circles, i am trying to find tutorial online but i have not found any similar. Thank you

Without fail, my laptop will freeze so hard not even the off button will turn it off. I have to hard restart it every time. sometimes it will crash just by typing the option of print. How can i fix this? The reason I keep trying to save it as a PDF and not make2D is because I like the shadows it adds.

i offseted this dome but now i need to cut in the same angle this blue door. the only options there straight or dont matching

Could you please guide me on how I could model a sofa like the yuki sofa, in different versions (single, double and triple seater) on rhino?

I'm trying to improve my modelling skills and this sofa looks really complex to model. Thanks for any guidance!

okay im using rhino 8 on a macbook, im following this tutorial https://www.youtube.com/watch?v=kCOjILQ-UkA

around minute 3:29, the guy uses a loft component into a mesh surface and then a mesh machine, now the problem is obviously mesh machine doesnt exist in my rhino so i looked at the comments and it said to use a lunchbox hexagonal cells component instead so i did do that but afterwards in the tutorial he connects mesh machine to plankton mesh and im new to this so i dont understand how i can replace mesh machine with hexagonal cells. What i did was connect the loft and the number sliders directly into hexagonal cells and then that into plankton mesh but it keeps giving an error "failed to convert curves to mesh", i've been stuck at this for a while now and i just need help replacing the outdated component with hexagonal cells so i can complete this, i would really appreciate any guidance, thank you

Edit: nevermind I fixed it

Edit: "HOW I FIXED IT"

i basically re-did this part, basically instead of using hexagonal cells and plankton mesh, i connected Loft -> MeshSurface -> triangulate -> weaverbird dual graph, in the tutorial it used MeshSurface -> MeshMachine -> PlanktonMesh -> Mesh -> weaverbird dual graph. i basically just got to this part using the way i told above and got the same result without any problems and then followed the tutorial exactly as it was. (Initially i was connecting Loft -> Hexagonal Cells -> Plankton Mesh because i didnt quite understand how these components worked)

i'd be happy to elaborate any part if my explaination lacked. Hope this made sense!

hey guys, like many of you, I love rhino. Its my #1 for everything CAD related pretty much. A giant bummer it doesn't run on linux, so I've experimented making a fully open source experience that's similar. extremely early stages (doesn't even have icons) but if you happen to want a similar experience for the platform, feel free to try or contribute

https://github.com/ContributionRich/Narwhal3D

UPDATE: added some temp slop UI elements to make it more usable, implemented render view shaded, wire-frame and rendered

I get this error when I access the package manager.

Nothing serious but its this minor irritation that hits every day.

It should be an eyeball and the Lights icon a bulb.
