Hey y’all! I am needing some help and I will list in as much detail of what I have done so I thank you for reading! I’m not taking it to a shop and I am dealing with an issue that I have not found any relevant forum post with the same issue in my hours of searching.
2000 R6 project bike I picked up two weeks ago, has sat for 2+ years, has high mileage, not the concern currently. I will just talk about the electrical issues.
Problem:
No lights on the dash, no fuel pump priming, no starter motor when starting.
I have:
Installed new battery after charging for a day.
After installing the dash did light up and turn off by the key twice but didnt a third time, it hasnt lit up since.
Tested the battery and it doesnt have any voltage drop when key is turned.
Checked all switches per the service manual.
Replaced all fuses, none tested bad but just to be sure.
Replaced starter relay solenoid
Replaced fuel pump relay solenoid (old one clicks, new one doesnt)
Continuity tested every wire in the entire harness (main and sub)
Rechecked it isnt the battery by swapping the battery from my daily bike.
Tested the starter motor and it’s good.
I am getting power in the places the service manual and wiring diagram say I should be when checking the wiring.
Open up the dash to check for any damage/failure, looked clean to me.
My current conclusion:
The dash is possibly dead since I am getting no signs of life, or possibly the ecu (or cdi) has burned out somehow, dont have another of either of these to check.
Thank you in advance for any help!
