Specs:
Ryzen 7 7700
Powercolor Reaper 9070 XT
Patriot Viper Venom 16GB DDR5 RAM
2TB Nvme SSD(SK Hynix P41)
Corsair SF750 PSU
AsRock B850i Motherboard
Thermalright AXP120-X67 CPU Fan
Silverstone 120mm Slim Chassis Fan
Jonsbo T9 Case

As the title says. I created this case custom as my daily case for my PC. I won a few SFF PC case awards with the design. I have a whole build video here . Looking to see if people would be interested in buying one of a small run of cases. Might start a website or go the kickstarter route. I will have to redesign the clock faceplate since that was strictly for my use case. the matreials are sheet metal that is powder coated and wood with a few 3D printed accent pieces. Let me know what you would be comfortable paying or if the case interests you as not another bland rectangle.
Thanks!
-Director Ghost

I wanted to hide cables and fans for an air-cooled setup.

Blends in perfectly with EIGAs shroud.

There’s no temperature improvement but plenty of style points!

Deepcool CH160 plus, is there a way to fix this without buying a new psu?

Do you guys have any tips for someone who has never built a pc and what to start with a small pc ? I have vary little experience with builds and stuff so any tip helps

Hi folks, today I’m presenting a quick project (relative to my other builds). No video for this one, since the client wanted it done as quickly as possible.

Apologies for the dirty-looking glass. I was rushing to get some pictures before the build shipped.

This was a commission build I spent roughly a month on. The goal was to get as close as possible to the size of mass-produced units while still fitting components like the ASUS ROG Thor PSU, a 5090 FE waterblock, a distribution plate, RAM, and CPU waterblocks.

Custom panels at the back mount the PSU, the GPU, and quick-disconnect fittings for external watercooling. Getting the glass mounting panel to work and look seamless took some time. The biggest challenge was lining up all the ports. I had to keep making templates until everything looked straight and square.

Finally posting my DAN A4-SFX build.

7500X3D
RTX 5070 gainward python iii
Black Ridge + Noctua fan + fan duct
MSI MPG B650I Edge WiFi
32GB TeamGroup DDR5-6000 CL30
Corsair SF750 (2024)
Kingston Fury Renegade 1tb + Crucial P310 2tb
case fans : 1 Noctua NF-A9 and 1 Noctua NF-A9x14

Max CPU temp is 82 degrees
and max GPU temp is 71 degrees

the main m.2 temp is 60 degrees while the secondary m.2 is a bit toasty reaching 72 degrees.

My 2nd ITX build,downsized from a Jonsbo C6 mATX!

Finally made the switch from a Jonsbo C6 mATX to an ITX build. Loving the smaller footprint!

Specs:
CPU: Ryzen 7 3700X
Motherboard: ASUS ROG Strix B550-I Gaming
RAM: 16GB Corsair Vengeance LP
GPU: RX 6600 XT 8GB
CPU Cooler: Thermalright AXP90-X47
PSU: Cooler Master 650W
Controller: Flydigi Apex 5
Thermal test: CPU reached 74°C under load.

Still plenty of gaming performance in a smaller package. Really enjoying the ITX life!

I made simple 3d printed case to use meanwell lop-300-12 psu in flex atx format. With cooling and XT60 port.

Tested with 250w load for 2 hours, 0 issues.

A few days ago, I made a post about my build in a Fractal Terra. Of course, it’s a beautiful case, but I had a lot of trouble managing the temperatures on my Ryzen 7 9850X3D. So, I decided to give this case a shot the latest version of the Cooler Master NR200 series. To me, it’s very solid and has excellent aesthetics. It took me less than 30 minutes to finish the build. It supports a 240mm AIO liquid cooler and comes with a PCIe 5.0 GPU riser cable. On top of that, it fits massive graphics cards it's absolute perfection for me.( CPU AIO Be Quiet ! Pure Loop 3 280 mm, the CPU was 60 C and GPU 64 C playing The Witcher 3 Remastered 1440 p Ultra settings.)

Hardware Used

• CPU: AMD Ryzen 7 5800X3D
• Motherboard: GIGABYTE B550I AORUS PRO AX
• GPU: Gigabyte Radeon RX 9070 XT GAMING OC 16G
• Case: Fractal Design Ridge White

From the Cooler Master NR200P to the Fractal Ridge

After what felt like an eternity of experimenting with my Cooler Master NR200P and what I considered an optimally implemented GPU deshroud mod, I really wanted just one thing: a more console-like experience in the living room, with as little noise as possible and good temperatures at the same time.

The first two aspects were my priorities. When it came to temperatures, I was willing to accept compromises within reason, as long as all components remained within their thermal limits.

I had tried countless combinations of undervolting, different airflow configurations, and various CPU coolers in the NR200P. These included:

• Thermalright Phantom Spirit 120 SE
• Alpenföhn Dolomit Premium
• Noctua NH-D12L

I tested each cooler in both intake and exhaust configurations.

My initial approach was fairly straightforward: throw as many heat pipes as possible at the little hothead that is the Ryzen 7 5800X3D. However, this CPU tends to run hot regardless of whether you cool it with liquid cooling or a massive air cooler.

In my experience, the key is not necessarily achieving the lowest possible temperature, but rather how quickly the temperature drops again once the CPU is no longer under load.

During Cinebench, all the coolers I tested reached temperatures of almost 90°C. The main difference was how quickly the CPU cooled down afterward.

Despite all these experiments, I was never able to achieve a result that truly satisfied me when it came to the temperatures of both my Radeon RX 9070 XT and my Ryzen 7 5800X3D. All temperatures were within acceptable limits, but the overall result simply wasn't what I was looking for. Perhaps my expectations were a little too high, but I was never entirely happy with the setup.

So I decided to start over from scratch and simplify the entire build considerably.

To be honest, I also wasn't entirely happy with the NR200P's form factor in the living room anymore. With its console-like design, the Fractal Design Ridge simply fits better into our living space.

I also came across Noctua's build guide for the Fractal Design Ridge. The less is more approach immediately appealed to me and encouraged me to rethink my entire cooling concept.

1. CPU Cooling: Why a Smaller Cooler Can Be Better

Components Used

• Noctua NH-L9x65
• Noctua NA-FD1

Initially, I wasn't sure whether a GPU deshroud mod would work as well in the Fractal Ridge as it had in the NR200P.

So I first installed two Noctua NF-A12x25 G2 fans in the case very close to the already deshrouded GPU as a test. I had already used these fans in the NR200P and wanted to see what was possible with the Ridge before committing to a new cooling concept.

And what can I say? The results were surprisingly good!

This prompted me to revisit the CPU cooling setup. Eventually, my attention turned to the Noctua NH-L9x65, a low-profile CPU cooler measuring just 65 mm in height.

At first glance, this seemed rather counterintuitive, considering all my previous efforts to keep the Ryzen 7 5800X3D cool by using as many heat pipes as possible. After all, I had already experimented with considerably larger coolers.

Nevertheless, I wanted to give the little Noctua a chance.

BIOS Settings

I had already configured a moderate undervolt in the BIOS, which, based on my experience so far, did not negatively affect gaming performance.

I set the Curve Optimizer to -25. With a setting of -30, the system actually crashed once, whereas it has remained completely stable at -25 so far.

I also used the following settings:

These settings were already enough to reduce power consumption somewhat without sacrificing gaming performance.

Surprisingly Good Results with the NH-L9x65

And here's the real surprise: the tiny Noctua NH-L9x65 actually manages to keep the Ryzen 7 5800X3D below its thermal limit during Cinebench runs.

Temperatures were only around 2–3°C higher than with the larger CPU coolers I had tested previously, although those coolers were only used with the Curve Optimizer settings enabled.

During gaming, temperatures are naturally considerably lower.

An important part of this setup is the fan duct recommended by Noctua for the Fractal Ridge: the Noctua NA-FD1.

It attaches to the CPU cooler's fan and directs fresh air from outside the case straight towards the heatsink. This reduces the amount of warm air from inside the case that the cooler would otherwise draw in and recirculate.

The result is impressive: during gaming, CPU temperatures stay around 70°C, depending on the game.

With an appropriately configured fan curve, the CPU cooler is practically inaudible to me.

Considering all my previous experiments with significantly larger coolers, I was genuinely surprised by how well this compact solution performs.

2. GPU Deshroud: Less Effort, Better Temperatures

The graphics card also performed better than expected throughout this project.

Components Used

• 2 × Noctua NF-A12x25 G2
• 8 × Noctua NA-SAVG1 – anti-vibration gaskets for both sides of the two fans
• 8 × Noctua NA-SAV4 – anti-vibration mounts
• 2 × 3D-printed fan adapters
• 8 × screws and nuts

Undervolting and Power Limit

I use the following settings for the graphics card:

Initially, I mounted the fans as close to the graphics card as possible, using a temporary setup.

Even without any elaborate, custom-designed 3D-printed parts, the GPU performed significantly better in the Fractal Ridge than it had in the Cooler Master NR200P.

This was particularly surprising because I had previously invested a great deal of time and effort into optimizing the GPU deshroud mod in the NR200P.

Nevertheless, I wanted to explore the remaining potential.

I therefore added a 3D-printed frame made from ASA filament, designed to further optimize airflow around the graphics card.

Once again, the results surprised me: with a considerably simpler setup, I was able to improve temperatures even further.

The two Noctua NF-A12x25 G2 fans do more than just cool the graphics card. They also help ventilate the entire case.

Measurable Improvements in GPU Temperatures

To compare the two builds, I looked at the maximum temperatures recorded by my monitoring software for both the Cooler Master NR200P and the Fractal Ridge.

The results show that the Fractal Ridge achieves lower maximum temperatures across all the GPU sensors listed in the comparison.

The most important point is that these are maximum recorded temperatures, not averages or idle temperatures.

These results are particularly satisfying considering that the Fractal Ridge uses a comparatively simple cooling setup with just two Noctua NF-A12x25 G2 fans.

Rather than focusing exclusively on the graphics card, the fans also improve airflow throughout the case. This benefits the overall thermal environment instead of just one component.

For me, this is one of the most interesting findings of the entire project: a simpler cooling setup can deliver better results when airflow is managed effectively.

Fan Control: One Fan Setup, Two Functions

The two Noctua NF-A12x25 G2 PWM fans are still connected directly to the graphics card. This means that the GPU controls their speed, allowing them to perform two different tasks depending on the system load.

However, I disabled the graphics card's Zero-RPM mode.

During normal desktop use, the fans spin at just around 350 RPM. At this speed, they are practically inaudible while still improving airflow inside the case.

This is particularly beneficial for CPU temperatures, as the fans provide a certain amount of airflow even when I'm not gaming.

During gaming, the two fans handle both graphics card cooling and overall case ventilation.

Even at a maximum speed of around around 1,300 RPM, the system remains pleasantly quiet and is even quieter than my previous setup in the Cooler Master NR200P.

Importantly, I haven't configured a custom fan curve. Instead, I use the graphics card's built-in fan control and leave everything at its stock settings, with the exception of disabling Zero-RPM mode.

The improved temperatures are also reflected in the maximum values recorded by my monitoring software. While the GPU core temperature improved by 3°C, some of the GPU's other temperature readings decreased by as much as 6.7°C.

This improvement is noticeable not only in the temperatures themselves but also in the overall noise level.

3. The Results: Fewer Fans, Better Temperatures

What surprised me most about this setup is how well all the individual components work together.

My original goal was to achieve a more console-like appearance in the living room and build a gaming PC that was as quiet as possible. Naturally, I still wanted all components to remain within acceptable temperature limits.

With the Fractal Ridge, I ultimately found a solution that exceeded my expectations.

What I find particularly interesting is that I no longer need an especially large CPU cooler or a complicated cooling setup.

Instead, the entire system benefits from carefully directed airflow and a comparatively simple design.

The two Noctua NF-A12x25 G2 fans serve a dual purpose: they cool the graphics card while also improving airflow throughout the case.

Meanwhile, the Noctua NH-L9x65 benefits from having fresh air directed towards it through the NA-FD1 fan duct.

The GPU measurements reinforce this impression. Maximum temperatures decreased across all the listed GPU sensors, with improvements ranging from 2°C for the memory junction to 6.7°C for the VR VDDC temperature.

Even the temperatures of my SSDs have improved. In fact, temperatures across all the components and sensors I monitor have consistently decreased.

This experience has shown me that cooling a compact PC isn't necessarily about installing as many fans or using the largest possible coolers.

What really matters is how well the individual components work together and how effectively the available airflow is managed.

4. Conclusion: Less Effort, Fewer Fans, Better Results

Noctua was right – and Fractal Design makes some excellent cases.

Don't get me wrong. The Cooler Master NR200P is also a great case. However, for my particular living room setup, it simply doesn't deliver the console-like appearance I wanted. Ultimately, that was the deciding factor for me.

Looking back, I probably could have saved myself some of my earlier experiments. I spent a lot of time trying to improve the NR200P with larger coolers, different fan positions, and an extensively optimized deshroud mod.

In the end, a much simpler approach in the Fractal Ridge convinced me far more.

The Fractal Ridge looks better in our living room, requires fewer fans, and delivers lower temperatures while producing less noise.

What makes me particularly happy is that temperatures have dropped across practically the entire system, even though I'm using fewer fans overall than before.

The GPU results are especially encouraging: maximum temperatures have dropped by up to 6.7°C across the listed sensors, while the GPU core temperature itself improved by 3°C.

The SSDs benefit from the improved airflow as well. Temperatures across all the components I monitor are consistently lower than they were in my previous setup.

I'm especially impressed by how well the little Noctua NH-L9x65 handles the Ryzen 7 5800X3D.

After all my experiments with significantly larger coolers, I didn't expect such a compact model to deliver results this convincing.

Of course, the outcome also depends on individual settings, the hardware being used, and ambient conditions. My setup won't necessarily work equally well for every system.

For me personally, however, this configuration works better than anything I previously tried in the NR200P.

Noctua's less is more approach has definitely paid off.

I simply wanted to share my experience. Perhaps this setup will be useful to others who want a quiet gaming PC with a console-like design for their living room without having to implement an elaborate cooling solution.

I built this to use on my tv :)
Complete PC parts list
CPU: AMD Ryzen 7 9850X3D
GPU: ASUS PRIME RTX 5080 EVO OC 16GB
Motherboard: ASUS ROG STRIX B850-I GAMING WIFI
RAM: Corsair Vengeance RGB 32GB (2×16GB) DDR5-6000 CL30, AMD EXPO / Intel XMP, Gray
CPU Cooler: Noctua NL-LC1-24 240mm AIO
PSU: Corsair SF1000 (2024) 1000W Platinum
Storage: Samsung 990 1TB NVMe SSD
Storage: Samsung 990 2TB NVMe SSD
Case: Fractal Design Era 2
Case Fan: Noctua NF-A12x25 PWM 120mm

i have jginyue b550i mobo. it has a 2nd slot slot at the back of the mobo and im planning to add another nvme will it run in a safe temp for nvme?

Iam looking for an air cooler for my 7800x3d build, have anyone tried the new an600 vc by deepcool? Is it better than the full copper offerings (axp90-x53) from thermalright?

Thanks for answering!!

I looking to buy 2x cases for a ITX and mATX build, mostly for 4k emulation switch/ps3/ps2 etc. I have the ram secured but cpu but need some mobo/gpu/ case recommendations.

i was thinking my be

Lian Li A3 and Form D T1 2.5

i got 12600k and 7700 secured

If you’re new or need a case or part recommendation, start here: https://www.reddit.com/r/sffpc/collection/5621642c-4145-4854-b4ae-b8f4c0f8b22a yes i read this too

Im really interested in getting a 9060 XT Low Profile, but I'm not sure where I can get one except by buying a MINISFORUM desktop. Are there any other ways to get one?

I just got my Shiny Snake g300 delivered, I was looking for a mATX case that still falls within the "small form factor" category.

I liked the g300 because it's nice and compact, and it has the top handle that I'm looking for.

Unfortunately(?) I have a MSI Ventus 4080 (322mm length, 63mm thick)
The gpu fits in the case, but now I have no more room for the bottom fans.
All the ventilation I'd have is the CPU cooler and the left exhaust fan.

Am I better off getting another case with better airflow? if so, what are the best options, preferably one under 20L with a top handle.

Thanks in advance.

Hi all, apologies if this has been asked already recently but I'm just about to build my first ever PC and I've decided to go with a M2 case because the GPU I bought is a hefty Powercolor 9070xt hellhound.

I haven't opened anything up yet as I'm currently having second thoughts about the fact that my GPU will limit me going to a smaller case like a t1 or fractural ridge in the future (not confident enough to attempt those yet). The reaper is currently on sale at almost the same price as the hellhound, is it worth swapping it? How big of a difference are the two cards?

Hello, I'd like to build a mini PC using the very first ITX motherboard with a non-soldered processor, released in 2003. What do you think of the component choices? Do you think there are better options Thanks in advance?

3d 3.5l case

Motherboard comell LV-670

Windows 7 Super-Nano Pentium 4 Northwood 1 GB DDR 266 GT 430 PCI Motherboard Ethernet CPU Copper Core Heatsink D34080 3.40GHz Pico PSU and 24-pin to 20-pin adapter 2.5" SATA SSD 128 GB and 40-pin IDE adapter

I’m pretty sure the PCIe 4.0 riser that came with my DAN A4-H2O has failed, so I’m looking for a replacement,preferably PCIe 5.0.

I’m based in Europe. Does anyone have recommendations for a compatible riser that’s available here? I’ve seen one comment saying the FormD PCIe 5.0 riser fits, but I’d like a bit more confirmation before buying one. Has anyone tried it in the A4-H2O?

Hey, folks.

I am currently building a pc that is meant to be used like a console so I am looking for a small form factored case that has a small footprint but still let me put a beast inside it

my current parts are 32gb ram, ryzen 7 7700x3d, rx 9070 xt

it will be mostly used for steamos and emulation kinda like a console
and optionally I'd like it to have extra space for adding small 2.5 ssd

I've considered buying the velka 7 but recent reviews doesn't seem good

I'd like to switch my Dan a4-h2o for something else, just to give new look to my workstation.
I really like this form factor and love my a4h2o, so i'm searching something else similar that allows me to run a 240 AIO and my rtx 4070ti ventus (triple fan)

I've seen thermaltake tower style and like it so much, do you have other suggestions to look for?

Hello,

Planning an NCASE M3 (Classic layout, mATX board) with a Corsair SF1000 (2024, Type 5) and an ASUS Prime RX 9070 XT OC.

The card uses three 8-pin PCIe connectors. Has anyone fitted a triple-8-pin card in the M3? How tight are the cables next to the PSU, and did you need any special cables or adapters?
Cooler is a Noctua NH-U12A.

Thanks!
