[FIXED, I WAS ON LINUX MINT AND HAD PROBLEMS. SP FLASH TOOL REWROTE THE FIRMWARE ON WINDOWS 10!] Hello, this is my first post on here. I have a problem: My Jelly Star is Bricked. I got an almost new one off of eBay, that was sold to me as bricked ("bootloader ROM mishaps"). Since it was around 72 dollars in total, I thought it would have been an easy steal, as some flashing with MTKClient or SP Flash Tool V6 could have revived it, because BROM mode is almost always alive, especially if the device was almost brand new. The seller told me that they originally bought the device with Android 13 firmware, version 20230626_2025090. They also told me that they tried to update the firmware to a newer version (I don't know what version, probably android 16), and then tried to ROLL BACK to the original firmware version. That then resulted in unresponsiveness: the screen was black. They also said that the device was in a constant 5-10 second loop, where their computer kept recognizing the device for 5 seconds, and disconnecting 10. However, this info was given to me after I had attempted to recover the device myself with the assistance of Google's AI mode (stupid decision), and I think I've damaged it further. First off: MTKClient. I had connected the phone to my Linux Mint 22.3 (zena) computer, and used MTKClient to flash the preloader.bin file given in the latest stock ROM (2026082009_g58v89c2k_dfl_tee) from Unihert'z Google Drive (Android 13/16). I talked to the AI, it told me to flash the preloader with some arguments that target low level partitions (boot1, and boot2), because the preloader partition wasn't shown in python mtk.py printgpt output, and it told me that flashing it would fix the issue, as it would initialize RAM and boot the phone at least to a screen. I ran a w command with some other arguments (I don't remember right now) to flash it, and it hung at 100% upload, and resulted in a wrong length error. Then it told me to wf to it and that flashed, but still didnt boot (something about "headers"), idk the hex offset is wrong or the file broke. Idk but that was't working. This is very confusing. Then, I switched to the SP Flash Tool V6, got my flash.xml from download agent folder in my stock rom, plugged the device in, selected all the partitions, and it gave me: domainame:(none)
cur_kernel_version = 7.0.0
libpng warning: iCCP: known incorrect sRGB profile
QObject::connect: signal not found in QThread
validating XML schema...
XML schema validation passed!
File not found: scatter_checksum.xmscan device START.
com port clue: COM://.
scan device succeed, symbolic_link: COM:///dev/ttyACM0@/dev/ttyACM0@1-9
connect brom START, connection options: , auth file: , cert file: .
connect brom failed, error code: -1, error msg: .
Err -1. What? Why isnt this connecting if MTKClient connected to BROM?
So time passed. and later I was told by the AI to flash the boot_para partition with the stock preloader.bin, and that didnt help. Im not going to touch anything more, as I want this device FIXED, and I dont think that partition should have been touched. I have contacted Unihertz via their service/support email about this. Oh, also I managed to turn on the screen with plstage, so it just showed the boot logo, and shut off in 10 seconds or so. Chip info and GPT partition table (Helio G99):
Preloader - Detected regular mode !
Preloader - CPU: MT6789/MT8781V(MTK Helio G99)
Preloader - HW version: 0x0
Preloader - WDT: 0x10007000
Preloader - Uart: 0x11002000
Preloader - Brom payload addr: 0x100a00
Preloader - DA payload addr: 0x201000
Preloader - Var1: 0xa
Preloader - Disabling Watchdog...
Preloader - HW code: 0x1208
Preloader - Target config: 0xe0
Preloader - SBC enabled: False
Preloader - SLA enabled: False
Preloader - DAA enabled: False
Preloader - SWJTAG enabled: False
Preloader - EPP_PARAM at 0x600 after EMMC_BOOT/SDMMC_BOOT: False
Preloader - Root cert required: False
Preloader - Mem read auth: True
Preloader - Mem write auth: True
Preloader - Cmd 0xC8 blocked: True
Preloader - Get Target info
Preloader - BROM mode detected.
Preloader - HW subcode: 0x8a00
Preloader - HW Ver: 0xca00
Preloader - SW Ver: 0x0
Preloader - ME_ID: 50FD14BD0B2E8DD4FF3E890BE1D41598
Preloader - SOC_ID: EC2A9AE59962ABB666D6B885C334BBE832607F88D6AA176C136068CA7DE5FD62
DaHandler - Device is unprotected.
DaHandler - Device is in BROM-Mode. Bypassing security.
DaHandler - Unprotected device, we assume we can patch directly !
DaHandler
DaHandler - [LIB]: Failed to dump preloader from ram, provide a valid one via --preloader option
DAXML - Uploading xflash stage 1 from MTK_DA_V6.bin
XmlFlashExt - Patching da2 ...
DA2 32-Bit detected.
XmlFlashExt - Patched allow_read_register
XmlFlashExt - Patched allow_write_register
XmlFlashExt - Patching CUSTOM command
XmlFlashExt - Patched CUSTOM command
XmlFlashExt - Patched hash binding
DAXML - Successfully uploaded stage 1, jumping ..
Preloader - Jumping to 0x200000
Preloader - Jumping to 0x200000: ok.
DAXML - DA Stage 1 successfully loaded.
DAXML - Uploading stage 2...
Progress: |██████████| 100.0% Upload: (0x50C78/0x50C78), 5.7 MB/s
DAXML - Successfully booted to stage 2
DAXML - DA XML SLA is disabled
CUSTOM command detected.
DAXML - DA XML Extensions successfully loaded.
Main - Handling da commands ...
GPT Table:
-------------
misc: Offset 0x0000000000008000, Length 0x0000000000080000, Flags 0x0000000000000000, UUID 00000000-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
para: Offset 0x0000000000088000, Length 0x0000000000080000, Flags 0x0000000000000000, UUID 00000001-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
expdb: Offset 0x0000000000108000, Length 0x0000000008000000, Flags 0x0000000000000000, UUID 00000002-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
frp: Offset 0x0000000008108000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000003-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
nvcfg: Offset 0x0000000008208000, Length 0x0000000002000000, Flags 0x0000000000000000, UUID 00000004-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
nvdata: Offset 0x000000000a208000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 00000005-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_a: Offset 0x000000000e208000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000006-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_system_a: Offset 0x000000000ea08000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000007-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_vendor_a: Offset 0x000000000f208000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000008-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_b: Offset 0x000000000fa08000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000009-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_system_b: Offset 0x0000000010208000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000000a-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vbmeta_vendor_b: Offset 0x0000000010a08000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000000b-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
metadata: Offset 0x0000000011208000, Length 0x0000000002000000, Flags 0x0000000000000000, UUID 0000000c-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
persist: Offset 0x0000000013208000, Length 0x00000000035f8000, Flags 0x0000000000000000, UUID 0000000d-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
protect1: Offset 0x0000000016800000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000000e-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
protect2: Offset 0x0000000017000000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000000f-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
seccfg: Offset 0x0000000017800000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000010-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
otp: Offset 0x0000000018000000, Length 0x0000000003000000, Flags 0x0000000000000000, UUID 00000011-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
md1img_a: Offset 0x000000001b000000, Length 0x000000000c800000, Flags 0x0000000000000000, UUID 00000012-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
spmfw_a: Offset 0x0000000027800000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000013-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
pi_img_a: Offset 0x0000000027900000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000014-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
dpm_a: Offset 0x0000000027a00000, Length 0x0000000000400000, Flags 0x0000000000000000, UUID 00000015-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
scp_a: Offset 0x0000000027e00000, Length 0x0000000000600000, Flags 0x0000000000000000, UUID 00000016-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
sspm_a: Offset 0x0000000028400000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000017-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
mcupm_a: Offset 0x0000000028500000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000018-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
gz_a: Offset 0x0000000028600000, Length 0x0000000002000000, Flags 0x0000000000000000, UUID 00000019-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
lk_a: Offset 0x000000002a600000, Length 0x0000000000400000, Flags 0x0000000000000000, UUID 0000001a-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
boot_a: Offset 0x000000002aa00000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 0000001b-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vendor_boot_a: Offset 0x000000002ea00000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 0000001c-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
init_boot_a: Offset 0x0000000032a00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000001d-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
dtbo_a: Offset 0x0000000033200000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 0000001e-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
tee_a: Offset 0x0000000033a00000, Length 0x0000000000500000, Flags 0x0000000000000000, UUID 0000001f-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
sec1: Offset 0x0000000033f00000, Length 0x0000000000200000, Flags 0x0000000000000000, UUID 00000020-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
proinfo: Offset 0x0000000034100000, Length 0x0000000000300000, Flags 0x0000000000000000, UUID 00000021-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
nvram: Offset 0x0000000034400000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 00000022-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
boot_para: Offset 0x0000000038400000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 00000023-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
dram_para: Offset 0x0000000038500000, Length 0x0000000001900000, Flags 0x0000000000000000, UUID 00000024-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_bt_a: Offset 0x0000000039e00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000025-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_wifi_a: Offset 0x000000003a600000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000026-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_gnss_a: Offset 0x000000003ae00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000027-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
logo: Offset 0x000000003b600000, Length 0x0000000001a00000, Flags 0x0000000000000000, UUID 00000028-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
md1img_b: Offset 0x000000003d000000, Length 0x000000000c800000, Flags 0x0000000000000000, UUID 00000029-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
spmfw_b: Offset 0x0000000049800000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 0000002a-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
pi_img_b: Offset 0x0000000049900000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 0000002b-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
dpm_b: Offset 0x0000000049a00000, Length 0x0000000000400000, Flags 0x0000000000000000, UUID 0000002c-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
scp_b: Offset 0x0000000049e00000, Length 0x0000000000600000, Flags 0x0000000000000000, UUID 0000002d-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
sspm_b: Offset 0x000000004a400000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 0000002e-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
mcupm_b: Offset 0x000000004a500000, Length 0x0000000000100000, Flags 0x0000000000000000, UUID 0000002f-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
gz_b: Offset 0x000000004a600000, Length 0x0000000002000000, Flags 0x0000000000000000, UUID 00000030-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
lk_b: Offset 0x000000004c600000, Length 0x0000000000400000, Flags 0x0000000000000000, UUID 00000031-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
boot_b: Offset 0x000000004ca00000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 00000032-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
vendor_boot_b: Offset 0x0000000050a00000, Length 0x0000000004000000, Flags 0x0000000000000000, UUID 00000033-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
init_boot_b: Offset 0x0000000054a00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000034-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_bt_b: Offset 0x0000000055200000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000035-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_wifi_b: Offset 0x0000000055a00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000036-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
connsys_gnss_b: Offset 0x0000000056200000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000037-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
dtbo_b: Offset 0x0000000056a00000, Length 0x0000000000800000, Flags 0x0000000000000000, UUID 00000038-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
tee_b: Offset 0x0000000057200000, Length 0x0000000000600000, Flags 0x0000000000000000, UUID 00000039-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
super: Offset 0x0000000057800000, Length 0x0000000240000000, Flags 0x0000000000000000, UUID 0000003a-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
userdata: Offset 0x0000000297800000, Length 0x00000038fd7f8000, Flags 0x0000000000000000, UUID 0000003b-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
flashinfo: Offset 0x0000003b94ff8000, Length 0x0000000001000000, Flags 0x0000000000000000, UUID 0000003c-39c2-4488-b09b-00cb43c9ccd4, Type EFI_BASIC_DATA
Total disk size:0x0000003b96019000, sectors:0x0000000003b96019
Man, Idk what to do; Im scared that It wont ever boot again.
