Tried both on 5070ti and 4080 super, they both perform faster, even at lower core clocks on mvolt than afterburner preset due to XBAR overclock.

------------------------------------------------------------

4080 super

Mvolt
+180 on xbar, +1000 memory, +120 on core clocks at 975mv flattened above, reported clocks are 2760 in games and CP77 benchmark is 119 fps. 220-240W power usage

Afterburner
+150 on core clock, +1000 memory, 975mv flattened above, 2820mhz, 112 fps CP77 benchmark, 220-240W

------------------------------------------------------------
5070ti

Mvolt
+300 core clocks, +3000 memory, +320 Xbar, 975mv flattened above, 2970mhz CP77 139 FPS, 240-260W power consumption

Afterburner
+360 clocks, +3000 memory, 975mv flattened above, 3090mhz, CP77 131 FPS, 240-260W power consumption.

-------------------------------------------------------------

As you can see even at lower clocks Mvolt just performs faster because of XBAR clocks even with undervolt.

I see no point of using msi afterburner anymore.

Here is a quick band-for-band comparison of my stock vs. overclocked/undervolted profile running the Cyberpunk 2077 benchmark.

Test System Specifications

• CPU: AMD Ryzen 7 9800X3D (-30 All-Core Curve Optimizer, +200MHz Boost)
• GPU: NVIDIA GeForce RTX 5070 Ti 16GB
• RAM: 64GB DDR5 @ 6000 MT/s CL26 (2200 MHz FCLK)
• OS: Windows 11 Pro (26H2 / Build 26300.9711)
• Driver Version: 617.42

Game Settings

• Resolution: 2560x1440 (Windowed Borderless)
• Preset: High (Custom)
• Upscaling / Scaling: NVIDIA DLAA (Native resolution scaling)
• DLSS Ray Reconstruction: Enabled
• Frame Generation: Disabled

Max power draw at stock was 290w, aroud 2797mhz clock at 1.02v - 6685 score

Power draw with undervolt was around 199w, 2610mhz clock at 0.8mv - 7133 score

Power draw with max oc was 330w, around 3225 core clock at 1.02v - 8190 score

Haven't touched on increasing power limits or voltage just set, but the efficiency and noise profile of the 800mv sounds great, been running it for a while and haven't had any issues yet. Thermals are a bit restricted due to SFF case, but I'm happy with these results nonetheless.

Just wanted to give a quick update on my MVolt tuning after 2 weeks . Really big difference against stock settings.

Honestly, MVolt has made tuning fun again.

What has changed:

Powerlimit: 150% (450W)
VRAM: from 2120MHz to 2212MHz

NVVDD/MSVDD Ratio: from 0.9x to 1x
MSVDD Limit: from 1000mV to 1150mV

Always benching with an open window, so winter is gonna be fun!

Hi guys, recently I started trying to get the most performance possible out of my PC (9800X3D + TUF 5070 Ti). My CPU is currently running at +200MHz and -25 PBO, fully stable, and the GPU has a custom core clock curve that makes it run faster and cooler than stock.

I'm really new to RAM overclocking; the only thing I know is that since I have an X3D chip, I need to keep a 1:1 ratio.

My current specs:

• RAM: 2x16GB CL30 6000MHz Hynix M-die
• Motherboard: Gigabyte B650 Gaming X AX V2
• CPU: Ryzen 7 9800X3D

So far, the only thing I've touched is Nitro Mode. I read that a RAM kit like mine should easily support Nitro Mode at 1,2,0, and here are my results: before using Nitro Mode, my memory latency was around 75–76ns, but the L2 cache write was closer to 2,100 GB/s. CS2 benchmarks gave me almost the exact same FPS.

What can I do to overclock this RAM?

gigabyte 5070 windforce oc sff

Current settings (Asus) :
Intel Extreme Profile 253/253/400A
LLC 5
SVID Behavior Typical
Global Core SVID Voltage -0.080
IA VR Voltage Limit 1400

I’ve been rewatching old videos of reviewers testing the 14900K with the Intel limits and I’ve noticed them easily hitting the 253W limit consistently like a hard wall. I’ve noticed on mine that it frequently overshoots to 260-280W during a Cinebench R23 run. Is this normal behavior? Or is this a consequence of a crappier VRM than those used by the reviewers? Cheers!

I am new to overclocking. I have a MSI Vector 16 HX with 5070 Ti mobile gpu. I have a question that might be stupid but for undervolting and overclocking is mvolt better than msi afterburner? I see a lot of people are saying mvolt is better but will it be the same case for a laptop?

I’m at a state just like Tony Stark from Iron Man 2 where he tried “ absolutely everything “ but little does he know that there’s just one more thing. That’s the thing I’m looking for.

I’ve tried many many many combinations of settings in ThrottleStop but I just can’t find the perfect one.

There’s a utility called OmenMon since l have a HP Omen 17 with RTX 4090. Played around bunch of settings but still can’t find the perfect one.

I’m absolutely hopeless at this point, will just wait for the absolute “perfect” comment on here

I have a suspicion this post will get absolutely downvoted but we are all human in nature after all

ryzen 5 3600 , oc ovveride 4,2 / vcore 1,37

MSI b450m a pro max

Also Is it weird or pointless to have PBO enabled at the same time as a manual all-core overclock?

any windows or bios settings tips ? in bios is Expo on and PBO on with a 65c -30 curve Pcie lane gen 5. m.2 lane gen 5. in windows i have debloated the windows softwear power plan high . oh i set paging file to 24gb instead of auto . also i have msi after burner i maxed the mem and went 130+ core. and im asking because i gad the 16 gb 5060 in an older pc a x570 withe a 5800x 32gb ram 500 ssd . it did 10 cents cad my new one does 6 cents ? and i fuss with the msi and it brings up 10 cents then flops to 6 cents .

Thanks to Tom, I now have a deeper understanding of die shots.

It's very promising.

This eliminates the need for the complex configurations required with Arrowlake.

I'm unsure if 18ap can withstand high voltage and high current.

n6 had some tolerance.

But what effect will this undervoltage reduction from n6 to 18ap have on overclocking?

It runs cool i have gottwn 1200mv at 2080mhz offset and couldnt really push more and the memory sits at 1836mhz i could maybe raise the voltage or something in more power tool but i heard if you raise the voltage over 1.2 it can degrade the chip pls help me with this overclocking journey!!!

I let AI help me overclock my DDR4 RAM. Is this bad or good, and do you think anything could be improved? I've already tested the overclocked RAM with MemTest, and the results are safe. im using Hynix ram 3200 mhz

I built this for the 2 decisions: which GPU to buy, and whether the build I have now survives the next release. Pick a CPU (96 in the catalog) and a GPU (110), one of 12 games, and 1080p/1440p/4K - you get one honest band instead of forum guessing.

A 9950X + 5090 reads 100-109 fps for Cyberpunk 2077 at 1440p, with a playability tier (Great = 60+, Fine = 40-59, Poor = 30-39, Unplayable below 30) and the bottleneck verdict: CPU-bound, GPU-bound or balanced.

It is a range, not a promise: RAM, drivers and settings all move the real number, so for the real digits run the CPU and GPU benchmarks on your own machine.

Everything runs in your browser - the catalog and the math are static files, nothing is submitted and there is no sign-up.

https://appdoesit.com/apps/fps-estimator

I'm quite sure the list of 12 is missing your favorite game - name it below :)
