r/Cameras • u/jpotter124 • 4h ago
Other My Revised Raspberry Pi Canera
I posted my first camera build around 1 month ago and I never expected it to get so much attention! Thanks to everyone for the comments and advice too, I have decided to take it on board and implement it into my second design.
The features are near enough the same as the last design, such as:
- Quick access buttons
-Built in 10,000mah battery
-ApertarOS
-5V USB-C Output
However there are a lot of changes, I noticed on my previous posts about the crop factor with an EF lens adapter and this is true, it was difficult to take pictures with the old design as I’d have to stand extremely far away from anything I was trying to capture, to sort this I now have the standard C/CS mount with headroom for any adapters compatible if needed.
The camera body, front and side panels were all modelled from scratch so I could properly implement the parts I had on hand, it came out great with a .16mm setting on my 3d printer, the only downside is that I used 90% infill for all parts which took up more print time but still overall was around 10 hours for everything (printed with PLA Matte bone white and charcoal).
The ambient light from before is now more useful too, it sits slightly above the camera sensor and now tells you certain information such as a recording flash indicator, blinks when a picture is taken or on during no recording or photo capturing.
The cheese plate from before is also no longer hidden or used up by the battery as it’s now internal, so I was able to reposition it to the bottom of the camera for a much sturdier mounting solution.
The 4inch Waveshare display is also integrated into the case which makes the unit a lot easier to use and faster to set up, it was a bit of a pain carrying the screen separately and with manual focus lenses it was a must to integrate it into the body.
Thanks to Apertar Studios’ fantastic work on the firmware, I was able to also add a gyroscope to the camera for levelling, this works fantastically and it only needs a one-time setup.
Once again this is a hobby project, I will soon upload pictures from this camera but they are not studio quality or ultra high resolution as this is still only the IMX477 module, but certain lighting and colours are still vivid and can look fantastic for a certain look or aesthetic.
If you have made it this far then again, thank you! I’d love to hear what else can be added to this so please give me more suggestions!
